ESD Boxes & Conductive Storage Containers
Source ESD boxes and conductive storage containers for electronic parts, PCB handling and production storage. Quandun’s range includes lidded totes, turnover boxes, storage containers and reinforced corrugated formats. Compare usable dimensions, access and the handling route, then specify the box, partitions and cover together for your purchase.
-

Carbon-Filled PP ESD Turnover Box
-

Lidded ESD Storage Tote for PCB Components
-

Nestable ESD Storage Box for Electronics
-

Reusable ESD Shipping Box with Reinforced Corners
Compare lidded storage box sizes
| Published model | Outside dimensions | Inside dimensions |
|---|---|---|
| QD-9805316 | 600 × 400 × 90 mm | 560 × 360 × 85 mm |
| QD-9805318 | 600 × 400 × 150 mm | 560 × 360 × 145 mm |
| QD-9805320 | 600 × 400 × 255 mm | 560 × 360 × 250 mm |
These published dimensions describe the named box bodies. The product page lists cover and anti-static partition options; confirm the exact compatible set, whether it is included and the remaining clearance with the cover and dividers fitted. Do not treat the inside height as the clearance under every optional lid.
Use the published dimensions to shortlist an ESD box
The lidded tote specification lists QD-9805318 and QD-9805320 with the same 600 × 400 mm outside footprint and 560 × 360 mm inside plan dimensions. Their listed inside heights are 145 mm and 250 mm. Compare these models when the height of the packed load changes, then verify the complete lid and divider assembly. The shared footprint does not establish a shared stacking interface.
Measure the component in its actual bag, liner or cushioning, not just the bare part. During sample approval, check that the lid closes without pressing on the contents, parts can be removed without catching, and the agreed compartments keep lots separate. Record the accepted model and accessory set so a repeat order uses the same configuration.
Match the container to storage or transfer
- Lidded tote: for a contained load where closure and stacking need to be specified together.
- Open turnover box: for repeated access to a supported load; compare the carbon-filled PP turnover-box family.
- Storage container: review the storage-box family and, if nesting is required for empty returns, confirm that feature against the selected model drawing.
- Reinforced corrugated box: for a different outer-container format; check the reinforced-corner box against the complete shipping package.
ESD box with lid or ESD safe divider box?
A lid and a divider solve different tasks. The lid retains contents; dividers separate parts, lots or kits. For multiple component types, send a compartment sketch and the packaged part dimensions, then request the divider drawing. See the ESD safe divider-box guide for a configuration example. Smaller drawer or front-access formats are in the ESD bin range.
Does a conductive box provide shipping protection?
What ESD means in electronics and shipping explains why charge-control properties and complete-package protection are different decisions.
Conductivity alone does not establish discharge shielding, impact protection or moisture-barrier performance. When contents leave an ESD protected area, define the inner protective package, cushioning, closure and outer box as a complete system. Use the electronics shipping-container guide to separate these requirements.
For a quote, provide the part envelope, package state, load, access frequency, compartment plan, route and required documents. Confirm the model revision and sample fit before approving repeat orders.
ESD container supply and repeat-order planning
For a bulk or repeat order, identify the selected box model, lid and divider configuration, quantities and delivery destination. Include the required electrical documentation and a drawing of any nonstandard compartment layout. Discuss company-level OEM and ODM options against the selected model before treating a requested change as available.
Request a quotation with the product link and configuration. Where individual components require a separate package, compare static shielding bags alongside the outer container.
