Features and advantages
Excellent anti-static performance:
It can effectively prevent the generation and accumulation of static electricity, quickly conduct static charge to the ground, and put the objects in the box in an electrostatically safe state, greatly reducing the risk of electronic components being damaged by electrostatic discharge.
Good physical properties: It is tough, wear-resistant, moisture-proof, corrosion-resistant, heat-insulating, and shock-resistant. It can protect internal items from external environmental factors such as moisture, chemical corrosion, collision, etc., ensuring the integrity and performance stability of the items.
Flexible and diverse design:
It can be customized according to different needs, including size, shape, color, partition method, etc. There are various structures such as stackable, hangable, and flip-top, which are convenient for users to choose according to actual usage scenarios and storage requirements. Some also have transparent panels and labels to facilitate identification of internal items.
Convenient and practical:
light weight, easy to carry and operate; stackable design can effectively save storage space and improve space utilization; can be well matched with a variety of logistics containers and workstations, suitable for various warehouses, production sites and other occasions, convenient for use in transportation, distribution, storage, circulation processing and other links.
Application Areas
Electronics industry:
widely used in the production, assembly, testing, packaging and transportation of electronic components, such as the storage and turnover of integrated circuits, transistors, capacitors, resistors, sensors and other electronic components, which can effectively protect these precision components from the harm of static electricity.
Communications industry:
used in the production and logistics of mobile phones, computers, tablets and other communications equipment and their components to ensure that key components such as electronic chips and circuit boards are not affected by static electricity during operation and transportation.
Aerospace:
In the manufacturing and maintenance of electronic equipment in the aerospace field, anti-static boxes with covers are used to store and transport various high-precision electronic instruments and components to ensure that they are not affected by static electricity in harsh environments.
Medical equipment:
During the production process of some medical electronic equipment such as pacemakers, blood glucose meters, medical ultrasound equipment, etc., anti-static boxes with covers are required to protect electronic components and ensure the safety and reliability of the equipment.
Technical Specification
| Product name | ESD Box | |||||
| Product model | QD-9805316 | QD-9805317 | QD-9805318 | QD-9805319 | QD-9805320 | |
 |
 |
 |
 |
 |
||
| Specification parameters | ●External dimensions: | 600*400*90mm | 600*400*130 mm | 600*400*150 mm | 600*400*220 mm | 600*400*255 mm |
| ●Inner size: | 560*360*85mm | 560*360*127 mm | 560*360*145 mm | 560*360*215 mm | 560*360*250mm | |
| ●Wall: | 3mm | 3mm | 3mm | 3mm | 3mm | |
| ●Bottom wall: | 5mm | 5mm | 5mm | 5mm | 5mm | |
| ●Weight: | 1.76kg | 1. 91kg | 2.29kg | 3. 1kg | 3.26kg | |
| ●Support Load: | 30kg | 30kg | 30kg | 30kg | 30kg | |
| Product description | ◆Static index: 10e4-10e8 Ω | |||||
| Color customization | □  □  □  □other |
|||||
| Optional accessories | □Port anti-static label | |||||
| Anti-static partition (GB306 series and GB307 series) | Anti-static partition (GB306 series and GB307 series) | Anti-static partition (GB306 series and GB307 series) | Anti-static partition (GB306 series and GB307 series) | Anti-static partition (GB306 series and GB307 series) | ||
| □Silk screen/hot stamping | ||||||
| □Box cover (QD-9805318L) | ||||||
| □Folder | ||||||
| □Turnover cart (QD-9806101 series) | ||||||
| Product name | ESD Box | ||||
| Product model | QD-9805321 | QD-9805322 | QD-9805338 | QD-9805346 | |
 |
 |
 |
 |
||
| Specification parameters | ●External dimensions: | 600*400*280 mm | 600*400*320 mm | 600*400*295mm | 600*400*320mm |
| ●Inner size: | 560*360*275 mm | 560*360*305 mm | 570*370*280mm | 555*355*315mm | |
| ●Wall: | 3mm | 3mm | 3mm | 3.2mm | |
| ●Bottom wall: | 5mm | 5mm | 5mm | 3.2mm | |
| ●Weight: | 3.01kg | 3.76kg | 3.75kg | 3.78kg | |
| ●Support Load: | 30kg | 30kg | 30kg | 30kg | |
| Product description | ◆Static index: 10e4-10e8 Ω | ||||
| Color customization | □ □ □ □other |
||||
| Optional accessories | □Anti-static label | ||||
| □Anti-static partition (GB306 series and GB307 series) | |||||
| □ Folder | |||||
| □ Silk screen/hot stamping | |||||
| □ Box buckle | |||||
| □ Box cover (QD-9805325L) | |||||
| □ Turnover cart (QD-9806101 series) | |||||
*Temperature resistance refers to the maximum temperature that the collection rack can withstand the PCB board
