ESD Carts & PCB Storage Trolleys
Source ESD carts and trolleys for moving PCBs, magazines and component containers between electronics workstations. Quandun’s range includes slotted PCB storage carts, width-adjustable formats and a low transfer trolley. Choose the load-support geometry first, then compare the route, wheels, brakes and verification requirements for the offered configuration.
-

ESD PCB Trolley QD-9805206
-

Large-Capacity ESD PCB Cart
-

Silent PU-Wheel ESD Trolley
-

Width-Adjustable ESD PCB Cart QD-9805201
-

Wire-Shelf ESD Trolley for PCB Storage
Compare PCB cart and magazine-transfer formats
| Published product | Load support | Published dimensions / fit |
|---|---|---|
| Width-adjustable PCB cart, 9805201-2 | Board grooves; not a general tray shelf | Listing shows 950 × 550 × 1380 mm and 1200 × 550 × 1380 mm variants, with corresponding maximum width settings of 850 and 1050 mm. |
| Large-capacity PCB cart, 9805208-2 | Slotted PCB handling | 1100 × 715 × 1400 mm; listed maximum width setting 445 mm. |
| QD-9806101 transfer trolley | Magazine racks or turnover boxes | Listed maximum outside size 810 × 470 × 140 mm; verify the usable support surface. |
The table summarizes the linked product listings. Outside dimensions and adjustment settings are not usable tray dimensions. For the 9805201-2 page, identify the specific offered variant and drawing rather than combining the larger width setting with the smaller frame.
Can a PCB trolley carry component trays?
Only when the proposed support actually carries the tray footprint and retains it during movement. A board groove is not a tray shelf. Provide tray outside dimensions, loaded height, loaded weight and removal direction, then ask for the supporting shelf or rail drawing. The ESD tray cart guide covers that interface.
Check turning, parking and the floor
Trial the representative load through the tightest turn and the normal parking point. Check handle clearance, brake access, load retention and transfer height. Request the exact wheel and brake arrangement; an accessory shown on one cart is not automatically included on another.
Electrical performance also depends on the assembled cart and its contact with the intended floor or grounding arrangement. A conductive wheel or metal frame alone does not establish a working path. Ask for the verification method and maintenance instructions, then include the cart in the site’s ESD control checks.
What to send for a trolley quotation
Provide the PCB, tray or magazine drawing; quantity per trip; loading side; route and floor conditions; working height; and required accessories. Compare the ESD cart selection guide for route checks and the magazine rack range when the load is a complete carrier.
ESD cart supply for electronics production
For a supplier comparison, identify the cart model, board or carrier dimensions, quantity per trip and number of carts required. Include aisle and doorway restrictions, loading height, floor conditions and the required wheel and brake arrangement. Ask for confirmation of the offered drawing and accessories as one configuration.
Request a quotation with the load drawing and route details. Discuss requested structural changes through the OEM and ODM service; confirm their availability for the selected cart before procurement.
