Product Introduction
Anti-static racks are storage devices designed to prevent static electricity buildup and discharge during storage, handling, and transfer. They are widely used in electronics, semiconductor, medical, and other static-sensitive industries. By reducing the risk of electrostatic damage, they help protect stored items while improving workplace safety, organization, and operational efficiency. These racks are also known as tray racks, anti-static tray racks, or anti-static turnover racks.
An ESD safe rack provides reliable protection for static-sensitive products, making it suitable for controlled production, inspection, and storage environments. ESD storage racks are also widely used to keep components organized and safely separated during material circulation.
Application Scenarios
Electronics manufacturing: Suitable for temporary storage and transfer of SMT components such as chips, LEDs, capacitors, and resistors, helping reduce static damage during production.
Laboratory: Used for dust-proof and anti-static storage of precision instruments, optical lenses, and medical consumables.
Warehousing and logistics: Helps classify and circulate static-sensitive products in different areas, improving workshop organization and 6S management.
Technical Specification
| Product name | ESD Rack | ||||
| Product model | QD-9805407 | QD-9805408 | QD-9805409 (4 slots) | QD-9805409 (9 slots) | |
 |
 |
 |
 |
||
| Specification parameters | ●External dimensions: | 415*285*200mm | 320*248*37mm . | 100*15*1 4mm | 100*15*1 4mm |
| ●Groove depth: | 5mm | 8.5mm | 10mm | 10mm | |
| ●Groove width: | 2.6mm | 5.5mm | 2mm | 1.5mm | |
| ●Pitch: | 10mm | 6.5mm | 18mm | 10mm | |
| ●Number of slots: | 38 | 35 | 4 | 9 | |
| ●Weight: | 1.74kg | 0.62kg | 0.006kg | 0.008kg | |
| Product description | ◆Static index: 10e4-10e8Ω | ||||
| Temperature resistance customization | 口 120°C 口 150°C | ||||
| Color customization | 口 口  口  口other |
||||
| Optional accessories | 口 Anti-static label | ||||
